Passenger
vehicles
Basic information | Brand | |
Model | T8 pro | |
Fuel Type | Diesel | |
Engine | 2.0CTI | |
Product Model | HFC1037DKT | |
Version | Full | |
Design Code | P3313 | |
Cab Type | L | |
Cabin | DOUBLE CABIN | |
VIN | LJ11PABD | |
Dimension | Overall Dimensions(L×W×H)(mm) | 5325*1880*1830 |
Rear body size (inner) | 1520*1520*470 | |
Wheelbase(mm) | 3090 | |
Tread (front / rear )FT/RT (mm) | 1540/1540 | |
GVW (kg) | 2755 | |
Curb Weight(kg) | 1855 | |
Payload(kg) | 900 | |
Seats | 2+3 | |
Mini Ground Clearance(mm) | 220 | |
FF/RF (mm) | 950/1285 | |
Max Gradeability(%) | 30 | |
Min Turing Radius(m) | 6.2 | |
Approach / Departure Angle | 30.9/23.3 | |
Power performance | Drive Mode | 4×2 |
Engine model | HFC4DB2-1B | |
Engine Type | Common Rail | |
Displacement (cc) | 1999 | |
Max Power (KW/r/min) | 102/3600 | |
Max Torque (Nm/r/min) | 320/1600~2600 | |
Emission | Euro III | |
Transmission Model | LC6T32 | |
Transmission | MT | |
Gear Ratio | 5.441;2.839;1.721;1.223; 1.000;0.794;R:4.935 |
|
Max speed (km/h) | 150 | |
Rear Axel Ratio | 4.1 | |
Chassis & Steering | Front suspension | Double wishbone independent suspension with spiral spring |
Rear suspension | Non-independent rear leaf spring suspension | |
Rear Differential Lock | — | |
Steering | Hydraulic Power Assisted Steering | |
Fuel tank capacity (L) | 76 |
