Passenger
vehicles
Overall specification | 12000*2550*3880 mm |
Seats | 50-65 |
Brand | Yutong |
Max. Speed (km/h) | 120 (Speed limit to 120 km/h) |
Luggage compartment (m³) | 11.5 |
Engine model | Cummins front mounted Diesel engine, L300 20, 300HP |
Displacement ( L) | 9.726 |
Fuel Tank Capacity (L) | 400 |
Emission Standard | China Manuel transmission |
Clutch | SACHS |
Gearbox &Retarder | Fast 6DS-148 with Retarder TB24 |
Axle | Feng Rear Axle 13,000KG, DRUM BRAKE |
Axle | Dong Feng Front Axle 8,000KG, DRUM BRAKE |
Suspension system | Leaf spring suspension |
Steering System | Integral power steering system |
Braking System | Dual-circuit air braking |
Tire | Tubeless tire 315/80R22.5 6+1 piece |
Door | Pneumatic front and middle doors, remote control lock |
Windows | Upper fix and lower sliding window |
seats | 66 passenger seats (3+2 seating arrangement)+1 driver seat+1 guider seat; safety belt for all seats |
A/C | 32000 kcal/h, imported Compressor |
Video system | Hard-disc player,front 19` Digital high definition display + middle 19`Digital high definition display, wire microphone |
Fire Extinguisher | 2kg fire extinguisher for passenger cabin, 2 automatic fire extinguishing for engine compartment |
Rear view system | Electronic Rabbit ear rear view mirror |
