Passenger
vehicles
| Overall Dimensions (mm) | 12000*2500*3955mm |
| Wheel Base (mm) | 6050mm |
| Wheel Track Front/Rear(mm) | 2148/1832mm；2048/1860 |
| Overhang Front/Rear (mm) | 2620/3330mm |
| App./Dep. Angle (0) | 9/10(°) |
| Max. Speed (km/h) | 100km/h |
| Color | yellow/blue/white |
| Curb quality | 13550kg |
| Total quality | 18000kg |
| Chassis | |
| Item | Detailed Data |
| Engine | Model:engine Wp10 336 Manufacture: Weichai power company limited., Ltd Engine position: Rear Fuel Type: Diesel Rated. Power (kw): 247kw Emission Standard: Euro Ⅲ |
| Clutch | Sachs MFZ 430 pull type, single piece dry type, diaphragm spring clutch, hydraulic control, pneumatic power |
| Transmission | Fast 6-speed manual transmission, short lever flexible shaft, remote control |
| Steering system | Mechanical hydraulic power steering system |
| Chassis | Load carrying body |
| Suspension | Air suspension system |
| Brake system / Automatic slack adjuster | Air brake, energy storge brake, Dual acting pneumatic brake system, braking clearance automatic adjusting arm , ABS |
| Retarder | Yes,with Retarder handle |
| Tire | 295/80R22.5 |
| Desel oil tank cubage（L） | 200L*2 |
| Battery / generator | 200Ah*2 |
| Body | |
| Passenger door | External swing door |
| Windows | Dark gray, full sealed window (exceot the rear two sides lower in-line sliding type) |
| Seats | 57/59 |
| Safety devices | Safety toughened glass, Emergency Hammer |
| Other | 2 roof hatch with ventilator； Soft folding curtain；digital clock；Driver window rolling blind/with side curtain |
| Media system | Radio with USB function |
