12m Electric City bus
12m Electric City bus
12m Electric City bus
12m Electric City bus
Zhongtong Electric City bus
Electric model
For electric city buses, the performance of the battery directly affects the product quality of the vehicle. Our 12-meter electric city bus is equipped with motors, electronic controls and other key components with a protection level of IP67. In addition, factors such as low energy consumption, fast charging mode, light weight, high level of safety protection, and convenient service are also guarantees for our operation to achieve profitability.
Share With :
Features
Specifications
ZHONGTONG LCK6122EVG CITY BUS
Specification
Model LCK6122EVG
Length 11990mm
Width 2540mm
Height 3280,3150mm
Gurb Weight 12200kg
 G.V.W 17900kg
Seats Number 70/10-42
Maximum speed 69km/h
Power Train System
Drive System WTEM80-40-2
Drive Method Four-gear motor AMT
Total Capacity 230.4
Battery Model Lithium iron phosphate
Voltage of controller (V) 540 (DC)
Rated/ Max. Power (Kw) 80/160
Chassis
Front / Rear overhang 2670/3220mm
Suspension Air suspension 2/4
Batteries Storage battery, 120 A.H x 2
Wheelbase 6100mm
Axle load 6400/11500kg
Front axle 7T, disc brake
Rear axle 13T, drum brake
Approaching departure angle 7/7°
Tire
Number of Tire 6
Size 275/70R22.5
