Overall Parameter | |
L*W*H (mm) | 11990*2500*3600 |
Inner height (mm) | 2040 |
Inner width (mm) | 2400 |
Wheelbase (mm) | 6000 |
Front/rear suspension (mm) | 2585/3405 |
Approach/departure (º) | 8.5/8.5 |
Ground clearance (mm) | 380 |
Max. gross weight(kg) | 18600 |
Capacity (seats) | 40+1 |
Turning R(mm) | 12200 |
Max. speed (km/h) | 90 |
Power train system | |
Battery model | Lithium battery |
Unit Voltage/capacity | 3.2V/20Ah |
Total KWH | 350 |
Motor model | Three-phase AC asynchronous motor |
Power train type | Direction |
Voltage (V) | 547.2 (DC) |
Rated /Max. power (Kw) | 142/230 |
Rated /Max. torque (N.m) | 800/2400 |
Running distance (km) | At least 250kms. (With Air-on, average speed 70km/h) |
Charging type | Slow charging model (3-4 hours, with 120kw charger) |
Connector/ Socket type | IEC62196 TYPE-2 |
Chassis | |
Front axle | Dena 7 T; disc brake |
Rear axle | Dena 13T, drum brake |
Suspension | Air suspension 2/4; |
Brake | Electric air pumper; dual-circuit air brake; front disc and rear drum brake; air drier; ABS; and rear automatic adjustment arm |
Tire | Michelin 295/70R22.5 ×6 |
Battery | 120Ah×2 |
Motor radiator | Electric fan |
Rear view mirror | Electric rearview mirror; inner mirror |
Air conditioner | ZHONGTONG 26000Kcal/h |
Seats | 45+1, ZTZY3072 model, ZTZY1021 adjustable driver seat |
