| Model | TR-180T | TR-200T | TR-300T | TR-350T | |
| Temperature Range(In Container) | -18℃ ~ +30℃ / 0℉ ~ +86℉ | -18℃ ~ +30℃ / 0℉ ~ +86℉ | -18℃ ~ +30℃ / 0℉ ~ +86℉ | -18℃ ~ +30℃ / 0℉ ~ +86℉ | |
| Cooling Capacity | 0℃/+32℉ | 2100W / 2442Kcal/h / 7160 BTU | 2200W / 2559Kcal/h / 7550 BTU | 3010W / 3500Kcal/h / 10270 BTU | 3815W / Kcal/h / BTU |
| -18℃/ 0℉ | 1100W / 1279Kcal/h / 3750 BTU | 1127W / 1311Kcal/h / 3840 BTU | 1770W / 2059Kcal/h / 6040 BTU | 2260W /Kcal/h / BTU | |
| Compressor | Model | 5H09 | 5H11 | QP16 | QP16 |
| Displacement | 87cc/r | 108cc/r | 163cc/r | 163cc | |
| Weight | |||||
| Condenser | Coil | Hydrophilic aluminum foil with internal ridge copper tube | Hydrophilic aluminum foil with internal ridge copper tube | Hydrophilic aluminum foil with internal ridge copper tube | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan | SPAL | ||||
| Dimensions | 890×720×200 mm | 890×720×200 mm | 890×720×235 mm | 890×865×235 mm | |
| Weight | 16 kg | 16 kg | 18kg | 21kg | |
| Evaporator | Coil | Aluminum foil with internal ridge copper tube | Aluminum foil with internal ridge copper tube | Aluminum foil with internal ridge copper tube | Aluminum foil with internal ridge copper tube |
| Fan | SPAL | ||||
| Air Flow | 900 m³/h | 950 m³/h | 1050 m³/h | 1800m³/h | |
| Dimensions | 725×560×160 mm | 603×538×230 mm | 845×646×230 mm | 1105×649×230 mm | |
| Weight | 12kg | 13kg | 15kg | 17 kg | |
| Voltage | DC12V / DC24V | DC12V / DC24V | DC12V / DC24V | DC12V / DC24V | |
| Refrigerant | R404a/1.2 kg | R404a/1.1 kg | R404a/1.3kg | R404a/1.2 kg | |
| Defrosting | Hot gas defrosting(Auto./Manual) | Hot gas defrosting(Auto./Manual) | Hot gas defrosting(Auto./Manual) | Hot gas defrosting(Auto./Manual) | |
| Total Weight | |||||
| Application | 5~12m³ | 8~12m³ | 10~15m³ | 15~25m³ | |
