Item Description | 45m3 |
Total lengh*width*height(MM) | 10800*2500*3990mm (For reference) |
Kerb mass(kg) | 9500(For reference) |
Tank capacity | 45m3 |
Tank material | 610L,tank thickness 3.5 mm,end socket thickness 4mm |
Walkway | Carbon steel walkway with ladder |
Discharge valve | Steel discharge butterfly valve |
Manhole | 2 pieces |
Discharge valve | 4 inch butterfly |
Discharge hose diameter | 4 inch |
Discharge hose length | 7000mm |
Unloading speed(t/min) | ≥1.2 |
Discharge residue rate(%) | ≤0.3 |
Rated pressure(Mpa) | 0.2 |
Axle | Standard 13-ton, 3 pieces |
Suspension | 4 pieces of plates |
King Pin | 2 inch |
Landing legs | Two speed manual operation |
Tyre | Linglong or Jinguan 12R22.5 12 pieces |
Rim | 22.5x9.0 12 pieces |
ABS | with |
Electrical system | 24V |
Diesel engine & Air compressor | Kefa, 4102 diesel engine,bohai dunhua 12m3/min air compressor |
