| Item | Q'ty | The main parameters | ||
| The shape parameters | The vehicle model | / | TS9408GRY | |
| Dimensions | / | 12000*2500*3850mm | ||
The frame configuration |
Axle | 3 PCE | Huajin 13T axle | |
| Suspension | / | steel suspension | ||
| Leg | 1 SET | JOST E100 | ||
| Kingpins | 1 SET | JOST 90 #, assembled | ||
| Tire | 12 PCE | Linglong 12R22.5 | ||
| Rim | 12 PCE | Xingmin 9.0-22.5 | ||
| ABS | 1 SET | Kemi 4S / 2M （Chinese brand） | ||
| Brake system | / | Dual-circuit air brake system; service brake, parking brake, emergency brake (breathe brake) | ||
Tank configuration |
The toal volume of tank | / | 42000L(including 5% ullage space) | |
| The number of compartment | / | 1 compartment | ||
| Material of tank | Head | / | 5083 /6.5mm | |
| Shell | / | 5083 /6.0mm | ||
| Anti-wave plate | / | 5083 /6.0mm | ||
| Manhole | 2 PCE | 20inch | ||
| Discharge system | Bottom valve | 1 PCE | 4 inches aluminum alloy | |
| Discharge valve | 1 PCE | 3 inches | ||
| Vapor Recovery System | / | No | ||
| Discharge pump | / | No | ||
| Delivery hose | 2 PCE | 3 inch rubber hose, with the pipe box | ||
| Fire extinguisher | 2 PCE | 8kg dry powder fire extinguisher | ||
| Ladder | 1 PCE | Steel | ||
| Tank top walkway | 1 SET | Carbon steel tank top anti-sliding walkway | ||
| Control box | 1 PCE | Carbon steel control box | ||
| Toolbox | 1 PCE | Carbon steel toolbox | ||
| Spare tire rack | 1 PCE | / | ||
| Lighting | 1 SET | LED lights | ||
| Reflective logo | / | 3M reflective logo | ||
| Safety Accessories | / | An anti-static drag strip, An antistatic reel, A Flammable liquids signs | ||
