| Engine | |
| Engine: | Cummins ISF3.8E6154 |
| Displacement: | 3.76L |
| Maximum output power: | 115kW |
| Maximum horsepower: | 154HP |
| Emission Standards: | Euro III |
| Fuel type: | Diesel |
| Rated speed: | 2600rpm |
| Gearbox | |
| Gearbox: | 651B |
| Number of gears: | 6 speed |
| Chassis parameters | |
| Chassis : | Foton |
| Chassis model: | BJ5089XXY-A3 |
| Track: | |
| Number of tires: | 6 |
| Tire specifications: | 7.50R16 |
| Rear axle speed ratio: | 4.33 |
| Basic parameters | |
| Drive form: | 4×2 |
| Wheelbase: | 3360mm |
| Body size: | |
| Total quality: | 8.275ton |
| Upper structure parameters | |
| Specfication of Tank | |
| Container Capacity(m³) | 4 |
| Filling Mouth Grand Clearance（mm） | 740 |
| Filling Circulation Time（s） | 20-25 |
| Precompressor Load Time（s） | 18-22 |
| Precompressor Lifting Time（s） | 6-9 |
| Max. Compression Strength（T） | 12 |
| Max.Discharge Strength（T） | 8 |
