| Model: CLY5257GJY | |
| Overall size (mm) | 9300(L)* 2500(W)*3200 (H) |
| Wheel base (mm) | 4325+1350 |
| Min. ground clearence(mm) | 240 |
| Min. turning diameter(m) | ≤24 |
| Max. Speed (km/h) | 90 |
| Chassis | |
| Manufacturer | Sino truck |
| Model | ZZ1257M4347C |
| Steering system | Power steering, ZF8098 steer machine |
| Transmission | Manual |
| Brake system | Front axle is disc brake, rear dual axle is drum brake |
| Tyre | Common tyre, amount:10+1, type: 11.00-20 |
| Air-condition | None |
| Engine | |
| Model | WD615.92 |
| Max. Power (hp) | 270 |
| Engine type | L6, four strokes, water cooled, supercharged inter-cooling diesel engine, EGR |
| Fuel type | Diesel oil |
| Tank body parameter | |
| Tank actual volume(m3) | 21.5 |
| Tank actual dimension(mm) | 6880*2496*1560 |
| Tank material | Carbon steel Q235 |
| Discharge | aluminum alloy DN80 |
| Discharge rubber hose | 2 set |
| Tank mouth | Two, Carbon steel, diameter: Φ500 |
| Oil pump | circular-arc cogwheel pump, 80YHCB-60 |
